Unit 2.1: Geodetic survey of an outcrop for road cut design
These materials have been reviewed for their alignment with the Next Generation Science Standards as detailed below. Visit InTeGrate and the NGSS to learn more.
OverviewStudents take an engineering approach to design a stable roadcut based on analysis of data collected through traditional and TLS- or SfM-based methods.
Science and Engineering Practices
Using Mathematics and Computational Thinking: Use mathematical, computational, and/or algorithmic representations of phenomena or design solutions to describe and/or support claims and/or explanations. HS-P5.2:
Planning and Carrying Out Investigations: Plan an investigation or test a design individually and collaboratively to produce data to serve as the basis for evidence as part of building and revising models, supporting explanations for phenomena, or testing solutions to problems. Consider possible confounding variables or effects and evaluate the investigation’s design to ensure variables are controlled. HS-P3.1:
Obtaining, Evaluating, and Communicating Information: Communicate scientific and/or technical information or ideas (e.g. about phenomena and/or the process of development and the design and performance of a proposed process or system) in multiple formats (i.e., orally, graphically, textually, mathematically). HS-P8.5:
Developing and Using Models: Evaluate merits and limitations of two different models of the same proposed tool, process, mechanism or system in order to select or revise a model that best fits the evidence or design criteria. HS-P2.1:
Constructing Explanations and Designing Solutions: Design, evaluate, and/or refine a solution to a complex real-world problem, based on scientific knowledge, student-generated sources of evidence, prioritized criteria, and tradeoff considerations. HS-P6.5:
Asking Questions and Defining Problems: Define a design problem that involves the development of a process or system with interacting components and criteria and constraints that may include social, technical, and/or environmental considerations. ￼ HS-P1.8:
Analyzing and Interpreting Data: Analyze data using tools, technologies, and/or models (e.g., computational, mathematical) in order to make valid and reliable scientific claims or determine an optimal design solution. HS-P4.1:
Analyzing and Interpreting Data: Analyze data to identify design features or characteristics of the components of a proposed process or system to optimize it relative to criteria for success. HS-P4.6:
Cross Cutting Concepts
Systems and System Models: Models can be used to predict the behavior of a system, but these predictions have limited precision and reliability due to the assumptions and approximations inherent in models. HS-C4.4:
Systems and System Models: Models (e.g., physical, mathematical, computer models) can be used to simulate systems and interactions—including energy, matter, and information flows—within and between systems at different scales. HS-C4.3:
Structure and Function: Investigating or designing new systems or structures requires a detailed examination of the properties of different materials, the structures of different components, and connections of components to reveal its function and/or solve a problem. HS-C6.1:
Stability and Change: Systems can be designed for greater or lesser stability. HS-C7.4:
Cause and effect: Systems can be designed to cause a desired effect. HS-C2.3:
Disciplinary Core Ideas
Wave Properties: Information can be digitized (e.g., a picture stored as the values of an array of pixels); in this form, it can be stored reliably in computer memory and sent over long distances as a series of wave pulses. HS-PS4.A2:
Information Technologies and Instrumentation: Multiple technologies based on the understanding of waves and their interactions with matter are part of everyday experiences in the modern world (e.g., medical imaging, communications, scanners) and in scientific research. They are essential tools for producing, transmitting, and capturing signals and for storing and interpreting the information contained in them HS-PS4.C1:
Developing Possible Solutions: Both physical models and computers can be used in various ways to aid in the engineering design process. Computers are useful for a variety of purposes, such as running simulations to test different ways of solving a problem or to see which one is most efficient or economical; and in making a persuasive presentation to a client about how a given design will meet his or her needs. HS-ETS1.B2:
Defining and Delimiting Engineering Problems: Criteria and constraints also include satisfying any requirements set by society, such as taking issues of risk mitigation into account, and they should be quantified to the extent possible and stated in such a way that one can tell if a given design meets them. HS-ETS1.A1:
Engineering Design: Design a solution to a complex real-world problem by breaking it down into smaller, more manageable problems that can be solved through engineering. HS-ETS1-2:
This material was developed and reviewed through the GETSI curricular materials development process. This rigorous, structured process includes:
- team-based development to ensure materials are appropriate across multiple educational settings.
- multiple iterative reviews and feedback cycles through the course of material development with input to the authoring team from both project editors and an external assessment team.
- real in-class or field camp/course testing of materials in multiple courses with external review of student assessment data.
- multiple reviews to ensure the materials meet the GETSI materials rubric which codifies best practices in curricular development, student assessment and pedagogic techniques.
- created or reviewed by content experts for accuracy of the science content.
This page first made public: Apr 24, 2018
This unit offers an alternative application for high-resolution topographic data from an outcrop. Using engineering geology methods and data collection from TLS and/or SfM, students design safe "road cuts" with low probability of failure for a proposed fictitious roadway along the side of a hill. Cut slopes or "road cuts" are constructed slopes along roadways in mountainous regions. The design of such slopes requires a safe slope angle, rockfall catchment ditch, and drainage provision. The decision of the slope angle is based on kinematic analysis for slope failures due to the orientation of discontinuities (bedding planes, joints, etc.) with respect to that of the proposed slope. Traditionally, discontinuity orientation data are collected from measurements directly on the outcrop. This can be dangerous and the accessible sites may not be fully representative of the cut as a whole. Remote methods such as TLS and SfM generate 3D models from which discontinuity data can be collected safely. In this unit students learn the workflow for designing safe cut slopes using discontinuity data collected from direct field observations and TLS or SfM and compare the methods and results.
Unit 2.1 Learning Outcomes
Students will be able to:
- Design and conduct a geodetic survey for the purposes of designing safe cut slopes, including:
- Topographic survey using a transit compass
- Collect discontinuity data while in the field using transit compass
- Extract discontinuity data from LiDAR/SFM-generated 3D models
- Perform kinematic analysis based on discontinuity orientations and slope azimuth.
- Propose slope design based on kinematic analysis results and rockfall trajectory charts
Unit 2.1 Teaching Objectives
- Cognitive: Promote student ability to integrate structural geologic, topographic and rockfall trajectory information for designing rock slopes along roadways.
- Behavioral: Facilitate development of further surveying skills and use of SplitFX and DipAnalyst softwares.
Context for Use
The content in Unit 2.1 was designed for upper-level geoscience majors in a course with field components. It can work in a field camp over three days of field collection and data analysis. It can also work in an academic year course such as engineering geology, structural geology, applied geophysics, remote sensing/GIS, geomorphology, or field methods. It can be conducted over approximately one lecture (introduction to geodesy to study cut slopes) and two labs (conducting a small survey of a feature, exploring and interpreting the collected data). Another option is to collect data during a one- or two-day field trip, followed by data processing and analysis during subsequent class periods.
If a LiDAR scanner or SfM collection platform is not available, this may be used in a classroom setting with a prepared data set. The material works well with SfM for a group of approximately thirty (or fewer) students in groups of two with an instructor and teaching assistant/s. If you use TLS, it is ideal to have not more than 12-16 students, as they can break into four teams of 3-4, which means each feature will have four scan positions (doable with a group of students in eight to ten hours) and gives each student time for hands-on scanner time. The number of students is more flexible using SfM, as data may be collected using a variety of cameras at the same time so many students can have hands-on data collection time. If both survey techniques are being used, larger classes can be accommodated but an additional teaching assistant might be helpful.
Prior student experience with basic structural geology concepts, topographic maps, trigonometry, and basic calculation skills is expected. Students also need to have prior experience in discontinuity orientation data collection (strike, dip direction, and dip) and plotting structural data on stereonets. More details of designing and conducting TLS and SfM surveys are covered in Unit 1-TLS and Unit 1-SfM. Unit 2.1 can be taught as the first exposure that students have to these methods or after doing a Unit 1 exercise, but the instructor should review the Unit 1 resources before teaching Unit 2.1. Unit 5 is the summative assessment for the module.
Description and Teaching Materials
Through the Unit 2.1 Road Cut Design Student Exercise (Microsoft Word 2007 (.docx) 1.8MB May8 18) , this unit introduces students to rock slope stability analysis using both high-resolution remote sensing (SfM or TLS) and traditional outcrop mapping. They also build their spatial reasoning skills through topographic surveying. The instructor provides a hypothetical route for a proposed road. The task of students is to put forward slope design recommendations in the form of cross-sections showing the proposed slope angles and sites of mid-slope benches/rockfall catchment ditches that would result from excavations to build a road. To do the full project including both field data collection and high-resolution topography (SfM or TLS) takes three days. Students can be broken into groups of two for most of the exercise. Teams of four may be needed for TLS scanner time, unless you have a very small class.
If done as a three-day exercise, the main elements of each day are:
- Topographic surveying – students take elevation data with Jacob staff and transit compass in order to generate topographic profiles and a rough topographic map. The topographic map will be used to draw longitudinal sections and cut slope design cross-sections. Although this step is not, strictly speaking, necessary if published maps are available, it has proven valuable for increasing student understanding of survey measurements and coordinate systems.
- Traditional Outcrop Mapping - students collect discontinuity data in the traditional way using dip and dip direction as measured by a compass and then to perform kinematic analysis to recommend safe slope angles.
- Point Cloud Data from SfM or TLS - students generate point clouds and then use them to derive discontinuity data, as an alternative to direct outcrop measurements.
The tasks involved in doing a cut slope design include:
- Deriving discontinuity data, which can be done by:
- Manual discontinuity data measurement in the field
- Extracting discontinuity data from point cloud using SplitFX software (high-resolution point cloud generated by TLS/SfM survey). Thirty-day trial licenses for SplitFX can be requested.
Overview of cut slope design
A cut slope design, an example of which is shown here, mainly includes reasonably safe cut slope angles and slope benches/catchment ditches. Slope angles are selected based on kinematic evaluation of rock discontinuities with respect to the proposed slope aspect and angle. Therefore, it is necessary to collect discontinuity orientation data and also survey the topography within a 60-100 meter buffer zone around the proposed roadway median. The width of mid-slope benches and catchment ditches are based on rockfall trajectory studies.
Instructor preparation steps
The instructor should select a route for the proposed roadway (see below for tips on good sites). The selected site should have a topographic relief that will require cutting the existing natural slope to build a nearly level roadway. Mark the median of the proposed roadway on the ground by placing stakes every ~100 m along route and recording elevations using a GPS unit. On Day 1, students should find the stakes and perform a topographic survey for 60-100 m along profile lines originating from each ground stake perpendicular to the roadway. For each profile, students should work out from the proposed road center, first in one direction and then in the other. Students will use their Brunton compass and a Jacob staff (or equivalent) to calculate elevation every ~20 m (using the elevation of the stakes marking the road as reference).
Day 1 Topographic Surveying
- Introductory presentation on cut slope design and conducting topographic surveys.
- Demonstrate topographic survey using Brunton compass and a Jacob staff (procedure is in the student exercise document). Provide students elevation values (from GPS) at each stake.
- Make sure students know to record relevant data: linear distance and vertical angles on field note book.
Walk the students along the hypothetical road route with the stakes placed by the instructor and overview how to do simple topographic surveys (using their Brunton compass and a Jacob staff). Students should then surveys topographic profiles for ~60-100 m in either direction from each ground stake. The profile lines should be perpendicular to the hypothetical roadway.
Back in the classroom or camp
Review how to calculate elevation values based on linear distance between two points and the vertical angle.
Show students how to construct a longitudinal section which is a topographic profile along the median of the proposed roadway. Instruct students to also show the road level on the longitudinal section. Students should allow a maximum of 6% gradient (slope of 0.06, 3.43°).
Day 1 Deliverables
1) Topographic contour map of the roadway area (within the limits of the profile lines) surveyed. Note: If students need more time allow them to turn it in the next day. Students should use 11x17" graphing paper.
2) A longitudinal elevation profile section along the proposed roadway showing the proposed road level (allow a maximum of 6% road gradient). Note: Students should use 11x17" graphing paper.
Day 2 Traditional Outcrop Mapping
- Kinematic analysis of rock slopes.
- What students should record in field notebook: Outcrop#, Lithology, Formation name, Type of discontinuity, Dip, Dip direction, Aperture, Continuity, Water flow, and Spacing.
Instruct the groups from Day 1 to locate two outcrops (in the vicinity of the proposed roadway) and collect discontinuity data (orientation, type, aperture, continuity, water flow, spacing) for at least 100 discontinuities. They will mainly be using orientation data for the project but it is a good practice to learn rock mass characterization.
Back in the classroom or camp
- Plotting discontinuity orientation manually and using software. DipAnalyst is the software described in this unit. Other options include RockPack III by RockWare or DIPS by Rocscience.
- Performing kinematic analysis using DipAnalyst software.
Day 2 Deliverables
Kinematic analysis results summary write-up with attached stereonet plots showing poles to discontinuities, slope, and a friction angle using software (DipAnalyst, RockPack III, DIPS). Each stereonet should represent expected slope aspects based on the orientation of the roadway and a slope angle of ~85°. For each expected slope azimuth, state the possible type of failure (plane, wedge, toppling) and an optimum slope angle that would minimize slope failure potentials.
Day 3 Point Cloud Data from SfM or TLS
- Structure from motion photogrammetry (SfM) and/or terrestrial laser scanning (TLS) basics if the students have not already learned the method/s. (See Unit 1-TLS and Unit 1-SfM for resources).
- How to generate point cloud using SfM and/or TLS and generate discontinuity data using SplitFX.
- Instruct students to watch the tutorial videos for SfM - Agisoft Photoscan Pro tutorial (MP4 Video 21.8MB Mar8 17) and Engineering analysis - SplitFX software tutorial (MP4 Video 44.7MB May10 17) or read prepared manuals and/or short user's guides (see below).
In the field
Have the students collect data for SfM and/or TLS using methods described in Unit 1. Students should obtain local coordinates for the SfM targets using a Brunton compass and measuring tape. Students should select a local origin (0, 0, 0) and record distance, vertical angle, and bearing from the chosen 0, 0, 0 point.
Back in the classroom or camp
Work with students as they:
- Process point clouds from SfM photos (or receive TLS point cloud data from a field engineer).
- Use SplitFX to determine discontinuities from the point clouds.
- Use DipAnalyst to perform kinematic analysis.
- Construct slope design cross sections for selected 3-5 profile lines that will show current topography and the proposed slope cut (see cut slope diagram above for an example).
- Write up their reports.
Day 3 Deliverables
- Students complete kinematic analysis using point cloud–generated discontinuity data and write a few lines discussing differences and similarities in using manually collected data for kinematic analysis.
- Detailed cross section for each selected profile also showing the slope design profile (similar to what is shown above).
Note: Students should use 8.5x11" graphing paper.
- Approximately Two-page summary write-up including
- Introduction of the project
- Geology of the area
- Discussion on genesis of discontinuity sets
- Kinematic analyses results with stereonets for the possible slope azimuths
- Justification of proposed slope angles (based on kinematic analysis), mid-slope benches and catchment ditches (based on rockfall charts by Pierson (1991). For example, one can justify gentler slope angles that result in less slope failures and narrower catchment ditch or steeper slope with wider catchment ditch.
- Day 1 Presentation: Introduction Cut Slope Design and Topographic Surveying (PowerPoint 2007 (.pptx) 6.6MB May8 18)
- Overview of rock slope stability analysis concepts and making simple topographic profiles.
- Day 2 Presentation: Kinematic Analysis (PowerPoint 2007 (.pptx) 12MB Apr22 18)
- Overview of rock slope failure and kinematic analysis
- Day 3 Presentation: Slope design from SfM (PowerPoint 2007 (.pptx) 9.9MB May8 18)
- How to use discontinuities determined from a point cloud to inform slope design
- Student readings
Student Reading: Introduction to Kinematic Rock Slope Stability Analysis (Microsoft Word 2007 (.docx) 622kB Apr22 18)
Student Reading: Slope Design Considerations (Microsoft Word 2007 (.docx) 1.2MB May8 18)
- Complement the instructor presentation for student reference
- For instructors who are new to these topics, be sure to review these readings before giving presentations
- Student exercise
Unit 2.1 Road Cut Design Student Exercise (Microsoft Word 2007 (.docx) 1.8MB May8 18)
- Survey design manuals
SfM Field Methods Manual for Students (Microsoft Word 2007 (.docx) 6.7MB Oct31 16)
TLS Field Methods Manual (Microsoft Word 2007 (.docx) 31.9MB Oct31 16)
- Include considerations for survey design for each method and specifics of TLS or SfM data collection
- Data-processing manuals (detailed)
SfM Data Processing and Exploration Manual (Agisoft Photoscan software) (Microsoft Word 2007 (.docx) 14.3MB Sep22 16)
TLS Data Processing and Exploration Manual (RiScan Pro software) (Microsoft Word 2007 (.docx) 5.1MB Sep22 16)
- General guides to using the software for data exploration and some processing; applies to all units, including 1, 3, and 4.
- Agisoft PhotoScan creates point clouds from sets of overlapping photographs. Versions available for Windows and Mac.
- SplitFX engineering software extracts discontinuity data from point clouds. Windows only.
- DipAnalyst performs a kinematic analysis of rock slopes based on known discontinuities. Windows only.
- Software quick-guides
Unit 2.1 Agisoft Quick Guide (Microsoft Word 2007 (.docx) 2.6MB May3 18)
Unit 2.1 SplitFX Quick Guide (Microsoft Word 2007 (.docx) 2.2MB May3 18)
Unit 2.1 DipAnalyst Quick Guide (Microsoft Word 2007 (.docx) 504kB May3 18)
- Tutorial videos
- SfM - Agisoft Photoscan Pro tutorial (MP4 Video 21.8MB Mar8 17)
- Generate point cloud using Structure from Motion method with Agisoft software (other available softwares are overviewed in the SfM Guide for Instructors and Investigators (Microsoft Word 2007 (.docx) 8.8MB Oct31 16))
- TLS - SCENE software tutorial (MP4 Video 24.1MB Mar8 17)
- Processing LiDAR scans from FARO-brand laser scanners into 3D point clouds. (Other scanner brands will have their own software but the steps in the process will be similar; see also TLS Data Processing and Exploration Manual (RiScan Pro software) (Microsoft Word 2007 (.docx) 5.1MB Sep22 16).)
- Engineering analysis - SplitFX software tutorial (MP4 Video 44.7MB May10 17)
- Engineering software that takes point clouds as input and identifies structural discontinuities along which failure is more likely.
- Riegl TLS Field Operation Manual and Workflow (Acrobat (PDF) 7MB Oct19 16)
- This workflow document was developed by UNAVCO for TLS field engineers using Riegl VZ400 scanners. It is largely applicable to several other Riegl scanners. While additional training and experience is needed to independently run a Riegl scanner, it can be a useful reference for instructors to understand the basics of Riegl scanner operation. If updates are published to this document, they will be available on the UNAVCO Knowledge Base (search "TLS"). Applies to all units.
- Prepared data set - Eldorado Canyon, Colorado
- Eldorado Canyon outcrop for road cut - SfM photos and metadata (Zip Archive 83.1MB May5 18)
- Set of 26 photographs from Eldorado Canyon, Colorado that can be used for a road cut design exercise.
- Point cloud generated from the photographs
- Discontinuity patches generated from the point cloud
Teaching Notes and Tips
- Each student group needs at least one transit compass and a 30-meter measuring tape in order to complete the topographic surveying. This exercise is written for a fairly low-relief area. If your field area is steep to the point of having very limited access, it may not be possible to do this Day 1 exercise. Alternatively, you could have students use a laser range finder to generate distances and angles to generate profiles.
- Computer power can be a significant limiting factor when using Agisoft for SfM analyses, particularly at field camps without computer labs. Student laptops will have a variety of speeds and capabilities. I found that having students use 10-15 photos per outcrop and only generating a low-density point cloud helped with this issue and was still sufficient for the discontinuity analyses.
- Give the students an overview map with the hypothetical roadway they will be developing drawn on it.
- Calculating the x-y-z coordinates of SfM targets was also a good method to explain x-y-z points in space. Students are so dependent on technology and had little or no understanding of coordinate systems.
- Although the tutorial videos and in-depth manuals are more comprehensive, students are really glad to have the quick guides for easy reference.
- The final road cut design may not be identical from one group to another. One group may design slopes with gentler slopes to minimize failure and provide a narrower rockfall catchment ditch. Another group may justify steeper slopes with wider catchment ditches. Students may also suggest slope-stabilizing methods such as rock bolts or wire meshes for steeper slopes. The important concept is being able to justify the proposed design.
Much of the formative assessment can be done through observations of and discussions with students individually, in pairs, or periodically in the whole group. Students may also hand in their work from the field, including field notes (atmospheric conditions, metadata) and sketch of survey setup. The work for formative assessment could be graded based on completion.
Summative assessment for Unit 2.1 is based on the completed student exercise, which includes details of their survey design and interpretation of the collected data. An assessment rubric is included in the student exercise. Summative assessment for the module as a whole will be evaluated at the end of the module in Unit 5. If students complete just Unit 1 and Unit 2.1, the Unit 5 topics we recommend that you choose from are "geologic outcrop with visible faulting" or "sequence stratigraphy."
Unit 2.1 Road Cut Design Student Exercise Example Rubric (Microsoft Word 2007 (.docx) 21kB Apr22 18)
References and Resources
- Borradaile, G., 2003. Statistics of Earth Science Data, Springer, New York, 351 pp.
- Goodman, R. E., 1989. Introduction to Rock Mechanics, John Wiley & Sons, New York, 562 pp.
- Hoek, E. and Bray, J. W., 1981. Rock Slope Engineering, 3rd edition, The Institute of Mining and Metallurgy, London, England, 358 pp.
- Pierson, L. A., Gullixson, F.C., and R.G. Chassie, 2001, Rockfall Catchment Area Design Guide Final Report, SPR-3(032), Oregon Department of Transportation, 92 pp.
- Piteau, D. R. and Martin, D. C., 1977, Description of Detail Line Engineering Geology Mapping Method; in Rock Slope Engineering, Part G: Federal Highway Administration, Reference Manual FHWA-13-97-208, Portland, Oregon, 29 pp.
- Watts, C. F., 2003. ROCKPACK III, Rock slope stability computerized analysis package. Part one—stereonet analysis. User's Manual, Radford University, Radford, Virginia, 27 pp.
