Lab 3: Mountains of Ice
The lab activity was developed by Jeff Lockwood of TERC and Alison Mote of the Ann Richards School for Young Women Leaders for the EarthLabs project.
Summary and Learning Objectives
In Part A of this activity, students investigate how massive ice sheets can alter the landscape and deposit their sediments in the ocean. In Part B, students examine the phenomena that trigger the onset of ice building and subsequent periods of ice melting—Milankovitch Cycles.
After completing this Lab, students should be able to:
- Explain how the advance and retreat of glaciers affect rates of deposition and other Earth processes.
- Describe the processes that enable glaciers and ice sheets to increase the rate of sedimentation at ocean margins.
- Identify the climate cycles and explain what causes them.
Open the Student Lab »
Fig. 1 - Icebergs can carry large amounts of sediment far from ocean margins. Source: USGS
Activity Overview and Teaching Materials
Detailed overview of what students will do in each lab activity, how long it will take, and what materials are required to complete the lab.
In Part A: Glaciers and Ice Sheets
In Part A, students explore the nature of glaciers and ice sheets. They watch a video (Time-Lapse Video: Retreating Glacier) that shows them how glaciers retreat and how calving takes place. Then they view an animation that shows the retreat of the Laurentide Ice Sheet over the past 20,000 years.
Time estimate: 25 minutes
In Part B: Why Do Ice Sheets Advance and Retreat
Students watch a video presented by Richard Alley that describes the Milankovitch cycles, variations in the orbital characteristics of Earth that lead to changes in climate. Students fill out a table summarizing the nature and period of each cycle. Then students interpret two graphs that show changes in climate over the past 5.5 million years that were caused by the Milankovitch cycles.
Time estimate: 25 minutes
Printable Materials
Download and print files needed for each lab activity, including images, data tables, and Stop and Think questions.
Right-click (Win) or control-click (Mac) the linked text below and choose
File > Save As... to save files to your computer.
- Lab 3 Stop and Think Questions (
PDF
This file is only accessible to verified educators. If you would like access to this file, please enter your email address below. If you are new to the site, you will be asked to complete a short request form. If you have already been verified by the EarthLabs project, you will be taken directly to the file download page.
Word
This file is only accessible to verified educators. If you would like access to this file, please enter your email address below. If you are new to the site, you will be asked to complete a short request form. If you have already been verified by the EarthLabs project, you will be taken directly to the file download page.
Suggested Answers
This file is only accessible to verified educators. If you would like access to this file, please enter your email address below. If you are new to the site, you will be asked to complete a short request form. If you have already been verified by the EarthLabs project, you will be taken directly to the file download page.
- Lab 3B Milankovitch Cycles handout (PDF (Acrobat (PDF) 290kB Oct28 21))
- Table B handout (PDF (Acrobat (PDF) 44kB Oct28 21) Word (Microsoft Word 2007 (.docx) 36kB Oct28 21));
Suggested Answers
This file is only accessible to verified educators. If you would like access to this file, please enter your email address below. If you are new to the site, you will be asked to complete a short request form. If you have already been verified by the EarthLabs project, you will be taken directly to the file download page.
Teaching Notes and Tips
What you need to prepare ahead of time, and general recommendations for classroom implementation, as well as guidelines and facilitation tips for leading class discussions.
General Recommendations:
- Read through the lab and teacher resources BEFORE introducing it to your students.
- Print out any paper-based materials before starting the lab.
- Have students keep a journal or notebook to record all of their notes, questions, and findings.
In Part A: Students watch two videos and an animation to learn about how glaciers and ice sheets erode the land then deposit sediments in the ocean as icebergs break off the edge of the ice sheet.
Facilitation Tips:
- If you show the video from your computer, pause the video at one or two minute intervals so students can take notes and ask questions.
- At the end of the Retreating Glacier video, point out the sediment that is visible in the glacier (lateral moraines).
- Note that the calving process occurs any time an ice shelf projects over an ocean margin. This is an important point since an increase in sedimentation in an ocean basin is indicative of a cold climate, and an advancing ice sheet, not a melting, receding glacier as shown in the first two videos.
Wrap Up: Go over the Stop and Think questions with students to make sure they realize that finding dropstones indicates a colder climate. If uniform layers of mud and fine sand are present in a core, this indicates warmer temperatures.
In Part B: Students learn about the 3 Milankovitch cycles by watching a video and filling out a table.
Facilitation Tips:
- If you show the Milankovitch Cycle video on your computer, pause after each cycle description and field any student questions.
- Point out to students that the diagrams used in the video are not to scale, in fact, not even close. Explain that the eccentricity of Earth's orbit is so small that the orbit would look like a perfect circle if seen from above the plane of the solar system.
Wrap Up: Discuss with students whether or not the Milankovitch Cycles might explain current global climate change. After students voice their views on the subject, display the Climate Change: How Do We Know graphic. Point out just how steeply the carbon dioxide levels, and subsequent temperature increases, is compared to natural cycles.
- It might be fun for students to demonstrate these three motions using their heads and bodies. Have them pair up and run through the cycles together.
Optional: Use a hula hoop, as Richard Alley did in the video, to demonstrate how the eccentricity of Earth's orbit changes.
Student Notebooks
Suggestions for how to use Student Notebooks for Lab 3.
The following items are suggestions for inclusion in optional printed student notebooks. The materials are linked in the Printable Materials section, above.
- Key Questions listed in introduction to lab
- Stop and Think questions
- Milankovitch Cycles handout from Lab 3B
- Table B: Milankovitch Cycles
Assessment
There are several options for assessment of student understanding of material introduced in this lab. Choose from the following list, or create your own assessments.
- Assessment Options:
- Assess student understanding of topics addressed in this investigation by grading their responses to the Stop and Think questions.
- Teachers may decide to collect and grade Table B.
- Written Test for Lab 3 (
PDF
This file is only accessible to verified educators. If you would like access to this file, please enter your email address below. If you are new to the site, you will be asked to complete a short request form. If you have already been verified by the EarthLabs project, you will be taken directly to the file download page.
Word
This file is only accessible to verified educators. If you would like access to this file, please enter your email address below. If you are new to the site, you will be asked to complete a short request form. If you have already been verified by the EarthLabs project, you will be taken directly to the file download page.
Suggested Answers
This file is only accessible to verified educators. If you would like access to this file, please enter your email address below. If you are new to the site, you will be asked to complete a short request form. If you have already been verified by the EarthLabs project, you will be taken directly to the file download page.
Science Standards
Lab 3 supports the following Next Generation Science Standards (NGSS):
Disciplinary Core Ideas
HS.ESS2A Earth Materials and Systems
Science and Engineering Practices
#2 Developing and Using Models
#4 Analyzing and Interpreting Data #8 Obtaining, Evaluating, and Communicating Information
Cross Cutting Concepts
#1 Patterns
#2 Cause and Effect
#3 Scale, Proportion, and Quantity
#7 Stability and Change
Examples of how students engage with the standards:
Lab 3A NGSS
![[creative commons]](/images/creativecommons_16.png)
Provenance: Jeff Lockwood
Reuse: This item is offered under a Creative Commons Attribution-NonCommercial-ShareAlike license http://creativecommons.org/licenses/by-nc-sa/3.0/ You may reuse this item for non-commercial purposes as long as you provide attribution and offer any derivative works under a similar license.
Lab 3B NGSS
Provenance: Jeff Lockwood
Reuse: This item is offered under a Creative Commons Attribution-NonCommercial-ShareAlike license http://creativecommons.org/licenses/by-nc-sa/3.0/ You may reuse this item for non-commercial purposes as long as you provide attribution and offer any derivative works under a similar license.
Go to
Next Generation Science Standards (NGSS)
Additional Resources
Explore background information and content extensions related to Lab 3.
Background information
Content Extensions
