Unit 2: Earthquakes, GPS, and Plate Movement

Karen M. Kortz (Community College of Rhode Island)
Jessica J. Smay (San Jose City College)

These materials have been reviewed for their alignment with the Next Generation Science Standards as detailed below. Visit InTeGrate and the NGSS to learn more.

Overview

Students analyze and interpret empirical data with mathematical techniques to identify Earth's crustal motion especially elastic behavior during earthquakes. They use their analyses to create an argument for areas that are safer to reside.

Science and Engineering Practices

Using Mathematics and Computational Thinking: Use mathematical, computational, and/or algorithmic representations of phenomena or design solutions to describe and/or support claims and/or explanations. HS-P5.2:

Using Mathematics and Computational Thinking: Apply ratios, rates, percentages, and unit conversions in the context of complicated measurement problems involving quantities with derived or compound units (such as mg/mL, kg/m3, acre-feet, etc.). HS-P5.5:

Planning and Carrying Out Investigations: Make directional hypotheses that specify what happens to a dependent variable when an independent variable is manipulated. HS-P3.5:

Obtaining, Evaluating, and Communicating Information: Communicate scientific and/or technical information or ideas (e.g. about phenomena and/or the process of development and the design and performance of a proposed process or system) in multiple formats (i.e., orally, graphically, textually, mathematically). HS-P8.5:

Engaging in Argument from Evidence: Make and defend a claim based on evidence about the natural world or the effectiveness of a design solution that reflects scientific knowledge and student-generated evidence. HS-P7.5:

Engaging in Argument from Evidence: Construct, use, and/or present an oral and written argument or counter-arguments based on data and evidence. HS-P7.4:

Constructing Explanations and Designing Solutions: Make a quantitative and/or qualitative claim regarding the relationship between dependent and independent variables. HS-P6.1:

Constructing Explanations and Designing Solutions: Construct and revise an explanation based on valid and reliable evidence obtained from a variety of sources (including students’ own investigations, models, theories, simulations, peer review) and the assumption that theories and laws that describe the natural world operate today as they did in the past and will continue to do so in the future. HS-P6.2:

Analyzing and Interpreting Data: Evaluate the impact of new data on a working explanation and/or model of a proposed process or system. HS-P4.5:

Analyzing and Interpreting Data: Apply concepts of statistics and probability (including determining function fits to data, slope, intercept, and correlation coefficient for linear fits) to scientific and engineering questions and problems, using digital tools when feasible. HS-P4.2:

Analyzing and Interpreting Data: Analyze data using tools, technologies, and/or models (e.g., computational, mathematical) in order to make valid and reliable scientific claims or determine an optimal design solution. HS-P4.1:

Cross Cutting Concepts

Stability and Change: Much of science deals with constructing explanations of how things change and how they remain stable. HS-C7.1:

Stability and Change: Change and rates of change can be quantified and modeled over very short or very long periods of time. Some system changes are irreversible. HS-C7.2:

Scale, Proportion and Quantity: Algebraic thinking is used to examine scientific data and predict the effect of a change in one variable on another (e.g., linear growth vs. exponential growth). HS-C3.5:

Patterns: Mathematical representations are needed to identify some patterns HS-C1.4:

Patterns: Empirical evidence is needed to identify patterns. HS-C1.5:

Cause and effect: Cause and effect relationships can be suggested and predicted for complex natural and human designed systems by examining what is known about smaller scale mechanisms within the system. HS-C2.2:

Disciplinary Core Ideas

Plate Tectonics and Large-Scale System Interactions: Plate tectonics is the unifying theory that explains the past and current movements of the rocks at Earth’s surface and provides a framework for understanding its geologic history. Plate movements are responsible for most continental and ocean-floor features and for the distribution of most rocks and minerals within Earth’s crust. HS-ESS2.B2:

Performance Expectations

Earth's Systems: Develop a model to illustrate how Earth’s internal and surface processes operate at different spatial and temporal scales to form continental and ocean-floor features. HS-ESS2-1:

This material was developed and reviewed through the GETSI curricular materials development process. This rigorous, structured process includes:

  • team-based development to ensure materials are appropriate across multiple educational settings.
  • multiple iterative reviews and feedback cycles through the course of material development with input to the authoring team from both project editors and an external assessment team.
  • real in-class or field camp/course testing of materials in multiple courses with external review of student assessment data.
  • multiple reviews to ensure the materials meet the GETSI materials rubric which codifies best practices in curricular development, student assessment and pedagogic techniques.
  • created or reviewed by content experts for accuracy of the science content.


This page first made public: May 28, 2019

Summary

GPS data can measure bedrock motion in response to deformation of the ground near plate boundaries because of plate tectonics. In this module, students will learn how to read GPS data to interpret how the bedrock deforms and moves, both absolutely and relatively, near the plate boundary in California and how that results in earthquakes. They will then apply the skills they developed and knowledge they gained to demonstrate their understanding of how GPS data has implications for future earthquakes in the region.

Learning Goals

Unit 2 Learning Outcomes

  1. Students will observe, describe, analyze, interpret, and apply time-series GPS data related to horizontal bedrock motion resulting from plate tectonics
  2. Students will interpret absolute and relative bedrock motion near plate boundaries and its relationship to earthquakes as measured by GPS
  3. Students will draw on GPS data to make a societal recommendation relative to earthquakes
    The Learning Outcomes for Unit 2 support Module Goals 1 and 2.
    Earth Science Big Ideas (link opens in new window)
    ESBI-1: Earth scientists use repeatable observations and testable ideas to understand and explain our planet
    ESBI-3: Earth is a complex system of interacting rock, water, air, and life
    ESBI-4: Earth is continuously changing
    ESBI-8: Natural hazards pose risks to humans

Unit 2 Teaching Objectives

  • Cognitive: Promote an understanding of the relationship between bedrock motion and plate movement at boundaries; provide examples of evidence of plate motion and its effects on society via earthquakes; provide students with a framework to understand relative movement of plates at plate boundaries and how that movement affects the likelihood of earthquakes
  • Behavioral: Promote skills development in reading and interpreting bedrock GPS time-series data and understanding of its relationship to plate movement; provide a framework for students to approach data reading and interpretation to solve problems like a scientist; give students opportunities to draw vectors, identify trends, and calculate rates
  • Affective: Encourage reflection about approaches to and difficulties with working with time-series GPS data

Context for Use

The content for Unit 2 is appropriate for introductory geology, natural disasters, environmental science, and other geoscience courses; sophomore-level courses in which geodesy is being introduced; or non-geoscience courses where the nature and methods of science are being investigated. Unit 2 activities can easily be adapted to serve small- or large-enrollment classes. They are designed to be flexible in their context and can be executed in lecture and lab settings as an in-class activity, a homework activity, and/or a collaborative lab exercise. For example,

  • Activities 1 and 2 can be completed as homework, and Activity 3 can be completed as an in-class activity or lab exercise;
  • Activity 1 can be completed in class, Activity 2 completed as homework, and Activity 3 completed in lab; or
  • All activities can be completed in-class and/or in lab.

In the Measuring the Earth with GPS module, this unit can be used in sequence with the other units or alone. If paired with Unit 3: Glaciers, GPS, and Sea Level Rise, this unit develops skills that students have the opportunity to then build on in a supplemental activity of Unit 3. This unit is an adaptation of Exploring plate motion and deformation in California with GPS.

Description and Teaching Materials

Introductory Lecture (5–10 minutes)

This brief lecture introduction provide context for Unit 3 by introducing students to:

  • A map of tectonic plates and locations of earthquakes
  • Elastic rebound theory and earthquakes
  • Think-pair-share asking students to brainstorm how scientists can measure plate movement and introduce the idea that GPS can be used to measure plate movement

Slides: Unit 2 Introductory slides (PowerPoint 2007 (.pptx) 11.1MB Oct14 19)

Unit 2 Introductory slides
Click to view

If students are already familiar with plate movement and earthquakes (or after they are briefly introduced), the discussion questions on the slides could instead be presented as a gallery walk. The following prompts can be used for the gallery walk:
  • Where do earthquakes happen around the world and why do they happen in those locations? Give specific examples.
  • Give an analogy explaining how earthquakes happen. Include: friction, stress, time.
  • Should communities care if the ground they are on is moving? Why or why not?
  • How could GPS be used to measure earthquakes?

Activity 1: Observe and Describe (50–70 minutes)

In this activity, students will learn how to describe scientific data by making careful observations of it. Students will conclude by using that data to make a logical scientific interpretation. The questions guide students through the process that scientists use when they work to solve scientific questions. This particular activity uses data from GPS stations in southern California to better understand bedrock motion near transform plate boundaries.

Students can complete this handout as homework, in-class individually or in small groups, or in a lab in small groups. The graphs in the handout itself should be supplemented with the large version for easier readability (see below)—if students are working in groups, one large set of graphs per group is enough. If this is done in class, suggestions for formative assessment discussions are given in the teaching tips, below.

Student activity handout:

Activity 2: Animation (10–20 minutes)

In this activity, students will watch an animation that illustrates how GPS can be used to determine the location of plate boundaries. It describes the difference between absolute motion and relative motion with regards to plate boundaries.

Students can complete this handout as homework, in-class individually or in small groups, or in a lab in small groups.

Student activity handout:

Animation:

Activity 3: Analyze, Interpret, and Apply (50–100 minutes)

In this activity, students will learn how to analyze and interpret scientific data after describing it. Students will conclude by using that data to support a recommendation they make about an issue relevant to society. The questions guide students through the process that scientists use when they work to solve scientific questions. This particular activity uses data from GPS stations near Parkfield, California, and southern California to better interpret plate motions near transform boundaries and earthquake risk that can be interpreted by analyzing GPS position near the plate boundary.

Students can complete this handout as homework, in-class individually or in small groups, or in a lab in small groups. The graphs in the handout itself should be supplemented with the large version for easier readability (see below)—if students are working in groups, one large set of graphs per group is enough.

Student activity handout:

All graphs and original data files

Below are files with handouts, graphs, and data used throughout Unit 2. GPS data all come from https://www.unavco.org/instrumentation/networks/status/pbo

  • All graphs of GPS data: Unit 2 GPS graphs (Acrobat (PDF) 1.4MB Oct7 18)
    • This handout contains larger versions of the GPS graphs. You may find it helpful to have a copy of these printed out for each table group—particularly for the graphs in which the students need to calculate an annual range of motion as well as a rate.
  • All Excel files of GPS data: Unit 2 GPS data (Zip Archive 7.3MB Oct4 18)
    • Contains information on the data sources as well as the original spreadsheet data and graphs from which the student exercises and handouts were generated. For instructor reference or to make changes to the way data are displayed.

Teaching Notes and Tips

General

  • Students do wrestle with some misconceptions related to what GPS data is measuring. For instance they may think the GPS station itself is moving rather than the ground it is attached to. They may also not realize that the earthquake hazard for a given area depends on the difference in movement between stations, not the movement from one station considered alone. Students also confuse positions (mm) with rates (mm/yr).

Activity 1: Observe and Describe

  • If Activity 1 is done as homework, you may wish to have students compare their answers for the first few minutes of class or lab to ensure they understand it. In particular, it may be useful for them to compare their answers to Questions 3, 4, 11, 17, and 18.
  • If Activity 1 is done in class, you may wish to have the students pause after certain questions for discussion. Students can compare their answers to the answers of other groups, or you may wish to lead a full-class discussion. In particular, if may be useful for them to discuss Questions 3, 4, 11, 17, and 18. For Question 4, if desired, you can assign different years to different groups, and they can compare answers across years.
  • Here are slides showing the GPS data and stations to aid in class discussions, if desired (graphs are to the right of the slides): Unit 2 GPS photos, locations, and graphs (PowerPoint 2007 (.pptx) 17.6MB Jul11 19).

Activity 2: Animation

  • If Activity 2 is done as homework, you may wish to have students compare their answers for the first few minutes of class or lab to ensure they understand it. Or, you may wish to show the animation again and have a full-class discussion. In particular, it may be useful for them to compare their answers to Questions 4–6.
  • If Activity 2 is done in class, you may wish to have the students discuss the animation after they watch it. In particular, students can compare their answers to the answers of other groups, or you may wish to lead a full-class discussion. In particular, it may be useful for them to compare their answers to Questions 4–6.
  • If you do not wish to assign the handout for students to complete while watching the animation, you can instead ask Questions 3–6, 7, and 9 as discussion questions after watching the animation.

Activity 3: Analyze, Interpret, and Apply

  • We recommend that students work on Activity 3 in small groups, so they can work collaboratively to solve the problems.
  • Activity 3 builds on skills learned during Activity 1 and concepts learned during Activity 2, so they should precede this activity. However, if your students are proficient at observing and describing data in graphs, it may be possible to skip Activity 1 (note that there are some concepts and skills that students build on that you may need to teach them).
  • Here are slides showing the GPS data and stations to aid in class discussion, if desired (graphs are to the right of the slides): Unit 2 GPS photos, locations, and graphs (PowerPoint 2007 (.pptx) 17.6MB Jul11 19).
    Unit 2 GPS photos, locations, and graphs
    Click to view

  • The Activity 3 Answer Key includes a rubric for the more complex question related to providing earthquake hazard advice and examples of student answers. If your students struggle with how to write high-quality answers, you could consider sharing the rubrics and sample student answers and asking students to evaluate what makes a high-quality answer. This may help them improve for next time.

Assessment

Formative Assessments

Activities 1 and 2 can be assessed formatively by using some of the questions as prompts for discussions, as described above in Teaching Notes and Tips. In addition, if the students are working in class or lab on the questions, the instructor can circulate and listen to student conversations and answer questions to ensure that the desired learning is occurring.

Summative Assessments

Activity 3 (as well as Activities 1 and 2, if desired) can be used as the summative assessment for this unit (Unit 2: Earthquakes, GPS, and Plate Movement). In addition to the student activity handout, the following assessments can be used as homework, quiz, or exam questions. There are open-ended and multiple-choice questions included. Also note that the Assessment page includes more general summative assessments that can be used for this unit as well.

References and Resources

This unit is an adaptation of Exploring Plate Motion and Deformation in California with GPS.

Additional Resources for Instructors:

  • Students can compare their predictions for the locations of earthquakes to the USGS Earthquake Map.
  • Here is a description of the 2004 Parkfield Earthquake.
  • A map of the Earthquake Shaking Potential for California can be found on the California Shaking Hazard Assessment website; students can compare their predictions in Activity 3 to geoscientists' predictions (note that the hazard assessment is also dependent on other factors, such as ground type).
  • The GPS Velocity Viewer allows students and instructors to view maps showing the horizontal vectors of GPS stations.
  • There is a UNAVCO GPS Spotlight on Station MASW describing the 2004 Parkfield Earthquake and afterslip.
  • There is a UNAVCO GPS Spotlight on Station P496, a station that experienced the same earthquake but was closer to the fault as one of the GPS stations used as part of the Assessment.
  • There is a UNAVCO GPS Spotlight on Station P227 describing the slip and afterslip during and after an earthquake.
  • There is a UNAVCO GPS Spotlight on Station CRBT describing high-frequency GPS observations during an earthquake.
