NEP system close up


View Original Image at Full Size

Close up of NEP system with air sparging pipes (small diamter) and soil-vapor extraction tubing (large diameter)
Originally uploaded in A Civil Action - The Woburn Toxic Trial:Resource Collections.

Image 9249 is a 1052 by 1592 pixel JPEG
Uploaded: May14 07


Last Modified: 2008-03-27 13:06:29
Permanent URL: https://serc.carleton.edu/download/images/9249/.jpg

The file is referred to in 1 page
Resource Type: Photos
Topics: Woburn:Wells G and H Superfund Site, Pollution Sources
Provenance
Scott Bair - Ohio State University
