UML INAA laboratory


View Original Image at Full Size

Gamma-ray spectroscopy system (automated sample changer). The detector is kept at liquid nitrogen temperatures (dewer under cave). The small box on top of the cabinet combines all the functions of the HV power supply, spectroscopy amplifier, and analog-to-digital converter. The resultant spectrum is shown on the computer screen. Click image to enlarge.

Image 8971 is a 548 by 1016 pixel JPEG
Uploaded: Apr17 07


Last Modified: 2007-06-11 09:59:56
Permanent URL: https://serc.carleton.edu/download/images/8971/uml_inaa_laboratory.jpg

The file is referred to in 2 pages
